T Slot Bolts 5/16
Product Title M6 Thread 20mm T-Slot Screw Bolt Carbon Steel 30 Ser. Average rating: 0 out of 5 stars, based on 0 reviews Current Price $8.02 $ 8. 02 List Price $16.99 $ 16.
T Track Bolts And Nuts
| Part Number | Thread Size A | B | C | D | E | F | G | H | Wt. (lbs) | |
|---|---|---|---|---|---|---|---|---|---|---|
| 1/2-13 | 2 | 7/8 | 5/16 | 1 1/4 | 1/2 | 9/32 | 1 1/4 | .22 | |
| 1/2-13 | 2 1/2 | 7/8 | 5/16 | 1 3/4 | 1/2 | 9/32 | 1 1/4 | .25 | |
| 1/2-13 | 3 | 7/8 | 5/16 | 2 1/4 | 1/2 | 9/32 | 1 1/4 | .27 | |
| 1/2-13 | 3 1/2 | 7/8 | 5/16 | 2 3/4 | 1/2 | 9/32 | 1 1/4 | .30 | |
| 1/2-13 | 4 | 7/8 | 5/16 | 3 1/4 | 1/2 | 9/32 | 1 1/4 | .33 | |
| 1/2-13 | 5 | 7/8 | 5/16 | 4 1/4 | 1/2 | 9/32 | 1 1/4 | .37 | |
| 1/2-13 | 6 | 7/8 | 5/16 | 5 1/4 | 1/2 | 9/32 | 1 1/4 | .44 | |
| 1/2-13 | 8 | 7/8 | 5/16 | 7 1/4 | 1/2 | 9/32 | 1 1/4 | .53 | |
| 5/8-11 | 2 | 1 1/8 | 3/8 | 1 1/8 | 5/8 | 3/8 | 1 1/2 | .39 | |
| 5/8-11 | 2 1/2 | 1 1/8 | 3/8 | 2 5/8 | 5/8 | 3/8 | 1 1/2 | .41 | |
| 5/8-11 | 3 | 1 1/8 | 3/8 | 2 1/8 | 5/8 | 3/8 | 1 1/2 | .44 | |
| 5/8-11 | 3 1/2 | 1 1/8 | 3/8 | 2 5/8 | 5/8 | 3/8 | 1 1/2 | .50 | |
| 5/8-11 | 4 | 1 1/8 | 3/8 | 3 1/8 | 5/8 | 3/8 | 1 1/2 | .55 | |
| 5/8-11 | 5 | 1 1/8 | 3/8 | 4 1/8 | 5/8 | 3/8 | 1 1/2 | .62 | |
| 5/8-11 | 6 | 1 1/8 | 3/8 | 5 1/8 | 5/8 | 3/8 | 1 1/2 | .72 | |
| 5/8-11 | 8 | 1 1/8 | 3/8 | 7 1/8 | 5/8 | 3/8 | 1 1/2 | .85 | |
| 5/8-11 | 10 | 1 1/8 | 3/8 | 9 1/8 | 5/8 | 3/8 | 1 1/2 | 1.00 | |
| 5/8-11 | 12 | 1 1/8 | 3/8 | 11 1/8 | 5/8 | 3/8 | 1 1/2 | 1.25 | |
| 3/4-10 | 2 1/2 | 1 5/16 | 7/16 | 1 1/2 | 3/4 | 7/16 | 1 3/4 | .64 | |
| 3/4-10 | 3 | 1 5/16 | 7/16 | 2 | 3/4 | 7/16 | 1 3/4 | .70 | |
| 3/4-10 | 3 1/2 | 1 5/16 | 7/16 | 2 1/2 | 3/4 | 7/16 | 1 3/4 | .77 | |
| 3/4-10 | 4 | 1 5/16 | 7/16 | 3 | 3/4 | 7/16 | 1 3/4 | .85 | |
| 3/4-10 | 5 | 1 5/16 | 7/16 | 4 | 3/4 | 7/16 | 1 3/4 | .95 | |
| 3/4-10 | 6 | 1 5/16 | 7/16 | 1 1/2 | 3/4 | 7/16 | 1 3/4 | 1.05 | |
| 3/4-10 | 8 | 1 5/16 | 7/16 | 7 | 3/4 | 7/16 | 1 3/4 | 1.25 | |
| 3/4-10 | 10 | 1 5/16 | 7/16 | 9 | 3/4 | 7/16 | 1 3/4 | 1.45 | |
| 3/4-10 | 12 | 1 5/16 | 7/16 | 11 | 3/4 | 7/16 | 1 3/4 | 1.75 | |
| 1-8 | 3 1/2 | 1 11/16 | 1/2 | 2 1/2 | 1 | 1/2 | 2 1/4 | 1.25 | |
| 1-8 | 4 | 1 11/16 | 1/2 | 3 | 1 | 1/2 | 2 1/4 | 1.50 | |
| 1-8 | 4 1/2 | 1 11/16 | 1/2 | 3 1/2 | 1 | 1/2 | 2 1/4 | 1.62 | |
| 1-8 | 5 | 1 11/16 | 1/2 | 4 | 1 | 1/2 | 2 1/4 | 1.75 | |
| 1-8 | 6 | 1 11/16 | 1/2 | 5 | 1 | 1/2 | 2 1/4 | 2.00 | |
| 1-8 | 8 | 1 11/16 | 1/2 | 7 | 1 | 1/2 | 2 1/4 | 2.40 | |
| 1-8 | 10 | 1 11/16 | 1/2 | 3 | 1 | 1/2 | 2 1/4 | 9 | |
| 1-8 | 12 | 1 11/16 | 1/2 | 11 | 1 | 1/2 | 2 1/4 | 3.10 |
T Slot Nuts And Bolts
T-Knob 5/16' x 18: $1.00: 973: T-Knob 3/8' x 16: $1.00. Most double cut or universal tracks are made for 't-bolts' as well as hex head bolts.The ideal type of track to use for your projects is a High-end Anodized Mini T-Track that has been specifically designed to accept hex head bolts. This ensures the least amount of play when the bolt. The Gibraltar 5/16-24, 2' Thread Length, Zinc Plated, Steel T Strap Bolt 2-1/2' Length Under Head, Grade 5, 1-1/2' Head Width x 5/16' Head Height can be found within the T-Slot Bolts category. As part of MSC Industrial Supply's Fasteners offering, this item can be found using MSC part number 03576261. Gold Bond: T-Slot Bolts: Part No. Description: A - Diameter (in) L - Length (in). 1 5/16: 17/32: 4.50: 9-0814-621.T-SLOT 1-8 X 3.50 LONG GOLDBND: 1 - 8: 3.50: 1.
